Video

• Number of Channel (Cam to Base ): 1, BNC, up to 3G
• Number of Channel (Base to Cam ): 1, Return, BNC, up to 3G-SDI

Audio

• Number of Channel (Cam to Base): 2 Analog, Mic (Phantom Powered) / Line
• Connector (Camera and Base Units): DB-9, female

Camera control

• Number of Channel (bidirectional): 1, DB-9, male
• Selectable: RS-232/422/485,485(2W)

1 GbE, 100/1000 Ethernet

• Number of Ports (Camera Unit): 2, RJ-45
• Number of Ports (Base Unit): 2, RJ-45

Electro-Optical

• Operating Wavelengths: 1270..1610 nm
• Optical Budget: 15 dB or 23 dB (by request)
• Available optical connectors: ST, LC

Power

Base Unit

• Power Input: 12..17 VDC
• Power Consumption: 5W max

Camera Unit

• Power Input: 12..17 VDC
• Local Power: Battery Mount (V-Mount or Golden Mount), 11-17 VDC
• Power Consumption: 5W max

Local Control Panel

Camera Unit

• Link Status with LED indicator
• Rx Power Warning LED indicator
• Rx Power Fault LED indicator
• LED indicators: SDI Camera Present / Temperature Overheat / Power

Base Unit

• Link Status with LED indicator
• Rx Power Warning LED indicator
• Rx Power Fault LED indicator
• LED indicators: Return SDI Present / Temperature Overheat / Power

Remote Microphone control

• Remote Mic Select Button
• Selected Mic Gain Control
• Selected Mic Phantom Enable

Case dimensions

• Camera Unit: 100 x 105 x 42 mm
• Base Unit: 100 x 105 x 42 mm
