PBX-CC-300
PROBOX Family cross-converter with frame synchronizer
PRODUCT OVERVIEW
Scaling converters provide high quality conversion for an entire source image for a range of needs, up, down or cross-conversion between SD and HD formats. The input signal is converted to the selected standard and synchronized to reference signal. Supported signals from 3G-SDI to SD-SDI.
Device support up to 8 channels of audio with delay compensation.
PBX-CC-300 converts Teletext and WSS between HD and SD formats.
ARC convert signals with different aspect ratios.
SFP option allows for fiber optics connectivity in the same unit.
- 3G/HD/SD up, down and cross converter
- SDI, HDMI inputs and outputs at the same time
- Frame synchronizer
- ARC
- Teletext and WSS support
- Audio gain adjustment
- Available with fiber I/O
- Fiber optic connectivity
- Compact design
TECH SPECIFICATIONS
Supported video standards
- SD 625i/525i
- HD 1080i 50/59.94/60, 720p 50/59.94/60
- 3G 1080p 50/59.94/60, Level A, 4:2:2
Inputs
- 1 x BNC SDI
- 1 x mini HDMI
- 1 x BNC REF, Bi- and Tri-level sync
External audio
- Analog audio, 4 channels (2 stereo pair), jack 3.5 mm x 4
- AES/EBU, 2 channels, jack 3.5 mm x 2
Electro-Optical
- Operating Wavelengths: 1310nm (1550nm and CWDM by request)
- Optical Budget: 25 dB
- Fiber SDI input/output, LC/UPC connector
Dimensions
- 100x105x33.5mm
ORDERING CODES
| PBX-CC-300 | Cross converter with frame synchronizer |
| PBX-CC-300 (A or E) | Cross converter with frame synchronizer, audio embedders |
| PBX-CC-300-(TR or T or R) | Cross converter with frame synchronizer and Fiber I/O |
| PBX-CC-300(A or E)-(TR or T or R) | Cross converter with frame synchronizer, audio embedders and Fiber I/O |
A: 4 channel analog line audio
E: 2 channel AES/EBU audio (2 stereo pair)
T: Fiber SDI Output
R: Fiber SDI Input
TR: Fiber SDI In/Out
All modifications retain the capabilities of the base version.
